BI DIRECT 32A 30MA RCBO

Product Overview:

• Brand: Cudis
• Current Rating: 32A
• Depth: 78mm
• Dimensions: (H)82 mm x (W)17.9 mm x (D)78 mm
• Guarantee: 1 Year
• Height: 82mm
• Mounting: DIN Rail
• Number of Modules: 1
• Number of Poles: Single Pole and Neutral
• Packaging Types: Each
• Product Range: ROSNBI
• Rcd Type: A
• Short Circuit Rating: 6kA
• Standards: BS EN 610009-1, BS EN 61009-2-2
• Tripping Characteristics: B Curve
• Tripping Sensitivity: 30mA
• Unspsc V18: 39121601
• Unspsc V24: 39121601
• Voltage Rating: 230V
• Weight: 0.15000kg
• Width: 17.9mm
• Bidirectional miniature RCBO with switched neutral
• Status indicator
• Can be locked in On or Off position [with additional locking product]
