10-16MM RESIN CABLE JOINT

Product Overview:

Our straight resin joint kits are ideal for joining cables together where a cable has been damaged or replaced.

Supplied with click together moulds and two part polyurethane resin for insulation making the installation as easy as possible.

• Cable Size Acceptance: 10mm²-25mm² Cross-section (3/4 Core)
• Cable Diameter Acceptance: 13mm-25mm Ø
• Voltage Rating: 3.6kV
• Connectors Included: 4x BS10, 4x BS16, 4x BS25
• Suitable for single and multiple polymeric and paper cables both stranded and solid copper/aluminium connectors.
• Performance tested to BS6910/HD623 / VDE0278
• Length: 260mm
• Width: 70mm
• Height: 67mm
