6A 30MA AFDD TYPE A

Product Overview:

Niglon AFDD6B1-06A Arc Fault Detection Device (RCBO)

The use of Arc Fault Detection Devices is now mandatory for single-phase AC final circuits supplying socket outlets (with a rated current no higher than 32A) in certain types of buildings i.e. In Higher Risk Residential Buildings (HRRB) In Houses in Multiple Occupation (HMO)In Purpose Built Student Accommodation, In Care Homes.

• B Curve Single Pole
• Max Rating: 6A 230V
• RCD Type: A
• Tripping Curve Type: A
• Breaking Capacity: 6kA
• Rated tripping current: 30mA
• Cable Capacity: 25mm2 10mm2 live out/neutral out
• Standards: BS EN 61009-1, BS EN 62606
• Dimensions (HxWxD) 18 x 113.5x 66mm
• Serial Arc Fault Protection: Yes
• Parallel Arc Fault Detection: Yes
• Single Module: Yes
